Fine Smart Electric Actuator

The fine smart electric valve actuator is equipped with a butterfly valve, and its operating life is higher than the standard of similar products. Small and lightweight, easy to disassemble and repair, and can be installed at any location.

product-483-417

Product Description

◆Powerful functions: intelligent, proportional, switch, and various signal output types;

◆Compact size: the size is only about 35% of similar products;

◆Light and cheap: the weight is only about 30% of similar products;

◆Beautiful and elegant: Aluminum alloy die-cast shell, fine and smooth, and can reduce electromagnetic interference;

◆Precision and wear resistance: The integrated design of the worm gear output shaft avoids the gap of the key connection and has high transmission accuracy. It is forged with special copper alloy and has high strength and good wear resistance.

◆Safety guarantee: Passed AC1500V withstand voltage test, F-class insulated motor, safety guaranteed:

◆Simple matching: single-phase power supply, simple external wiring, 380V, DC power supply can also be used:

◆Easy to use: No refueling, no inspection, waterproof and rust-proof, installation at any angle:

◆Protection device: double limit, overheating protection, overload protection:

◆Multiple speeds: full travel time 9 seconds, 13 seconds, 15 seconds, 30 seconds, 50 seconds, 100 seconds (set before leaving the factory);

◆Anti-corrosion and anti-rust: The whole machine bracket, couplings and screws are all made of stainless steel:

◆Intelligent CNC: The intelligent control module is highly integrated into the electric device body, eliminating the need for an external positioner. Digital setting, digital tuning, high accuracy, self-diagnosis, one machine with multiple functions.

Match With Trunnion Ball Valve

product-474-439

Introduction

Trunnion ball valve is a new generation of high-performance ball valve, suitable for long-distance pipelines and general industrial pipelines. Special considerations have been taken in its design such as strength, safety, and resistance to harsh environments. It is suitable for various corrosive and non-corrosive media. . Compared with the floating ball valve, when it works, the force generated by the fluid pressure in front of the valve on the ball is all transmitted to the bearing, and the ball will not move toward the valve seat, so the valve seat will not bear excessive pressure, so the trunnion ball valve has small torque, small valve seat deformation, stable sealing performance and long service life. It is suitable for high pressure and large diameter occasions. The advanced spring pre-valve seat assembly has self-tightening characteristics to achieve upstream sealing. Each valve has two valve seats, which can be sealed in each direction, so the installation has no flow restrictions and is bidirectional. This valve is generally installed horizontally.

Detailed display

product-516-479
