Electric Soft Seal PTFE Flange Butterfly Valve

Butterfly valve structure principle
Butterfly valve (also known as flap valve) is a regulating valve with a circular valve disc or disc as the closing part. It is mainly composed of a valve body, a valve stem, a butterfly plate and a sealing ring. The valve body is cylindrical, with short axial length and built-in butterfly plate. The butterfly plate of the butterfly valve is installed in the diameter direction of the pipe. In the cylindrical channel of the butterfly valve body, the disc-shaped butterfly plate rotates around the axis, and the rotation angle is between 0° and 90°. When it rotates to 90°, the valve is fully open.
