electric actuator
Product composition
Internal accessories
Electronic components are selective
Optimal electronic components are indispensable
High-quality all steel gear motor
The performance of high quality motors from well known manufacturers is stable and reliable
304 stainless steel screw assembly
Assembled with genuine 304 stainless steel screws to avoid corrosion
Alloy steel gear sets are used inside
The high-quality alloy steel material and the professional heat treatment process ensure the high and reliable operation of the actuator
Power-off manual switch function
In the event of a temporary power outage or other situation, the manual function can be used to switch the valve switch urgently
High quality brass nickel plated inlay nut
It avoids the rusting of brass and is still fastened reliably even after multiple disassembly and assembly
High-precision inner octagonal mounting shaft
The octagonal mounting shaft makes it extremely easy to install the valve, increasing efficiency and saving time. High-precision size reduction and improved accuracy
Meets ISO5211 standards
F3 Ø36 4*M4 F5 Ø50 4*M5
Octagonal hole size 11*11mm
Hole S17mm
Rated voltage AC220V
Rated current 0.1A
Rated torque 25Nm
Running time 10S
Rotation angle 0-90°
Protection level IP67
Dimensions：Length 135mm width 88mm height 105mm
Electric ball valve
Stainless steel ball valves up to DN32
Valve torque may vary by manufacturer
subject to actual conditions
Brass ball valves are available up to DN65
Valve torque may vary by manufacturer
subject to actual conditions
Plastic ball valves are assembled up to DN50
Valve torque may vary by manufacturer
subject to actual conditions
