Stainless Steel Strainer Filter

product-431-305

Introduction

The flange Y-shaped filter, also known as a dirt remover or filter valve, is an indispensable device in the pipeline system for conveying media. Its function is to filter mechanical impurities in the media, and it can filter rust, sand particles, and small amounts of solid particles in the liquid in sewage to protect the accessories on the equipment pipeline from wear and blockage, and to protect the normal operation of the equipment.

The national standard Y-shaped filter is a small equipment that removes small amounts of solid particles from liquids, which can protect the normal operation of the equipment. When the fluid enters the filter cartridge with a certain specification of filter screen, its impurities are blocked, and the clean filtrate is discharged from the filter outlet. When cleaning is needed, only the detachable filter cartridge needs to be removed, processed, and reinstalled. Therefore, maintenance is extremely convenient. The national standard Y-type filter, also known as a dirt remover or filter valve, is an indispensable device in the pipeline system for conveying media. Its function is to filter mechanical impurities in the medium, and it can filter rust, sand particles, small amounts of solid particles in the liquid in sewage to protect the accessories on the equipment pipeline from wear and blockage, and to protect the normal operation of the equipment.

Classifications

1. The air filter cleans the polluted air to the state required for production and daily life, that is, to achieve a certain level of cleanliness.

2. The liquid filter cleans the contaminated liquid to the required state for production and daily life, that is, to achieve a certain level of cleanliness.

3. The network filter blocks junk information by setting it up, making the information appearing on the computer screen as much as possible meet the requirements. The principle of simultaneous absorption separates light of different colors

4. A light filter that absorbs some unwanted light. The above mentioned filter should be a mesh filter. In fact, there are many types of filters, such as laminated filters, sand filters, carbon filters, etc. The main principle is to use the pore size of the filter medium to intercept substances smaller than the pore size of the medium. Of course, some filter media also have special effects such as adsorption. Most filters are not so troublesome to backwash, as long as water is introduced from one end of the filtered water into the medium of the reverse backwash filter, a good backwash effect can be achieved. This type of valve should generally be installed horizontally in pipelines.
