Quarter-turn Electric Actuator

product-676-312

Performance features

(1)Signal interruption protection function.
(2)Over torque protection function.
(3)Mechanical and electric double limit switch travel protection function.
(4)"Remote auto / remote manual / local" three states can be switched, and with on-site electric operation, field hand wheel operation functions.
(5)Positive and negative effects conversion function.
(6)Prevent the motor run-down, with the dynamic electrical braking function.
(7)High performance servo motor,Can be frequently start without heat.
(8)Variety of control modes: Can be received standard current signal , Passive contact signal and Bus Signals.
(9)Supply voltage can be produced according to user requirements.

Actuator description

Type	Torque	Voltage	Speed	Install method	Control method	Special function	Code description of each part
OA	Output torque						Working torque,digital representation,unit:Nm
AS		K					Single phase 220V.AC 50Hz
BS		F					Three phase 380V.AC 50Hz
A+RS		Power supply					Rating travel time(90°),digital representation,unit:S
B+RS			Travel time	H			Foot-plate installation
				Z			Directly mounted installation
				Control method	G		Standard integration proportional modulating,4-20mA
					Y		Remote controlled, on-off input
					N		Intelligent, 4-20mA imput
					C		Main line
					Control method	P	With machine operating
						Ex	Explosion-proof
						----T	Special requirements: high, low temperature, working voltage, dimension, travel, etc.

Note: 1.The electric actuator required by the special technology needs to write clearly and concretely in order.

2.When A+RS100/K30HGP model is A+RS, the working torque is 1000Nm, single-phase power supply, the whole travel time is 30 seconds, and foot-plate installation with integration proportional modulatin with the local operationegration proportional modulatin with the local operation

Basic Parameters

product-551-411
